Outdoor IP65 LED Scrolling Message Board Signs , Dual Color Led Display
Product Details
| High Light | led scrolling sign,led scrolling display |
||
|---|---|---|---|
Product Description
Outdoor IP65 LED Scrolling Message Board , Dual Color Led Display
Quick Detail:
1, Outdoor IP65;
2, To display in single red, single green,single yellow and double color;
3, Available at outdoor P10, P16 and P20 etc;
4, AC110V and AC230V switch;
5, Asynchronous control system;
6, Small and big LED sign customized.
Description:
1. Double color LED message display is usded to display text and simple picture;
2. Outdoor message LED display high brightness insure clear seeing even under the brightful sunlight;
3. Scrolling LED message board is easy and convenient to edit and update message any time;
4. LED sign is showing message asynchronously;
5. Digital LED sign is controlled by computer or laptop;
6. LED digital sign is of multi signal input like RS232, RJ45, USB port etc.
Applications:
Church LED Sign
Store Use LED Sign
Windows LED Sign
Schoole LED Sign
Station LED Signs
Message LED Display
LED Message Displays
Information LED Sign
LED Information Display
Single Color LED Display
Double Color LED Screen
Monocolor LED Displays
Biocolor LED Message Board
Multi Color LED Display Boards
Specifications :
| LED Module Parameter | |
| Pixel pitch (mm) | 10 |
| Pixel configuration | 1R1G |
| Encapsulation | DIP346 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 32 x 16 |
| Module pixel | 512 |
| Module size (mm) | 320 x 160 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 96 x 96 |
| Cabinet pixels (pixels) | 9216 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 50 |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 10000 |
| Brightness(cd/m2) | ≥4000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 110°; Vertical 70° |
| Best viewing distance (m) | ≥8m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | / |
| Gray Grade | 512 |
| Display Color | 1024 |
| Refresh Frequency (Hz) | ≥200 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video procrssor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Front & Rear |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1. Electric LED sign is active and attractive compared with traditional sign boards;
2. LED digital sign is of higher brightness to display text and information clear and vivid, consumers could see its info in a far distance;
3. Digital LED sign is convenient to edit and update advertising information anytime, allowing more advertising in one LED signage;
4. Easy operation. By a computer or laptop, the displaying information and text is editted, added and delete there by few simple steps;
5. LED message display is utilizing RS232, RJ45 and USB connection, this multi signal input makes it wide options for customer;
6. Cost saving: Scrolling LED message display is utilizing asynchronous control method and not requires a computer or laptop equipped and running all the time.
