TV Studio Outdoor Rental LED Display / Led Video screen DIP246

  • img.alt
  • img.alt
  • img.alt
  • img.alt
Place of Origin China
Brand Name YUCHIP
Certification CE,ROHS,FCC,EMC
Model Number OR-8D
Minimum Order Quantity 1sqm
Price Negotiable
Packaging Details Flight Case,Wooden Case,Strong Carton Box
Delivery Time 15-20 Working Days
Payment Terms T/T
Supply Ability 5000㎡/Month
Product Details
High Light

full color outdoor advertising led display

,

led video screens
Leave a Message
Product Description

TV Studio Outdoor Rental LED Display / Led Video screen DIP246​





Quick Detail:



1, LED Chip: Epistar;

2, IC: MBI5024;

3, Power Supply: YHY ultra thin model;

4, Control System: Nova star;

5, Refresh Frequency: ≥2800Hz

6, Cabinet: Die casting aluminum cabinet material with hanging up and on stand structure.





Description:



1, The P8 outdoor rental LED display is used in concerts;

2, High refresh frequency guarantee P8 ultra thin outdoor rental LED display capable for scoreboard use in stadium;

3, Packed into flight case, convenient movment from one site to next;

4, This P8 die casting aluminum outdoor rental LED screen is used in road shows;

5, The ultra slim rental LED wall is used in musical events;

6, Outdoor rental LED display is being use widely around the world for multi rental use, bring good revenue to intestors.







Applications:



Concerts

TV Studios

Private Parties

Fashion Shows

Product Launches

Press Conferences

Political Gatherings

Programe Live Broadcast







Specifications :



LED MODULE PARAMETER
Pixel pitch (mm) 8
Pixel configuration 1R1G1B
Encapsulation DIP246
Colors matches 6:3:1
Module resolution (pixels) 40 x 40
Module pixel 1600
Module size (mm) 320 x 320
LED CABINET SPECIFICATION
Cabinet size (mm) 640 x 640 x 90
Cabinet resolution (pixels) 64 x 64
Cabinet pixels (pixels) 4096
Cabinet material Aluminum
Cabinet weight (kg) 12.5kg
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2) 15625
Brightness(cd/m2) ≥7000 (adjustable)
Brightness adjusted 100 grade by software or by Auto-optic induced
View angle Horizontal 110°; Vertical 70°
Best viewing distance (m) ≥7m
Communication distance(m) <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km
Display work method 1/4 Scan
LED driving method Constant driving current
Color contrast ratio 1800:1
Gray Grade 16bit
Display Color 439, 804, 651, 110
Refresh Frequency (Hz) ≥2800
Picture display method Intellective control technology , test-itself technology , correct technology, Synchronization
Control
Input signal DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting )
System operating WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level IP65
Working temperature(ºC) -20～+60
Stored temperature (ºC) -30～+80
Operation humidity(RH) 0-95%
Display Lifetime(hours) 10 years or more( natural environment)
100000 hours( ideal environment)
Maintenance Rear side
Working Voltage AC110 / AC220V±10% 47～63HZ
Out of controlled dot ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one)







Competitive advantages:



1, P8 ultra slim outdoor rental LED display is specially designed to be used as rental LED display.

2, Its main ad, antage is die cast aluminum cabinet,ultra slim thickness,hanging up rental LED screen structure;

3, P8 ultra slim LED screen utilizing DIP246 LED and brightness reaches about 8000cd/㎡,making it vivid image and video presentation even under direct sunshine light.
4, Brightness adjustable makes it suitable for both outdoor and indoor use;

5, DIP246 is better in waterproof aspect;

6, All high quality materials ensure the long life tim.



TV Studio Outdoor Rental LED Display / Led Video screen DIP246 0TV Studio Outdoor Rental LED Display / Led Video screen DIP246 1





TV Studio Outdoor Rental LED Display / Led Video screen DIP246 2TV Studio Outdoor Rental LED Display / Led Video screen DIP246 3
