Waterproof Outdoor Rental LED Display Hire , Led Matrix Display for Product Launches

  • img.alt
  • img.alt
  • img.alt
  • img.alt
Place of Origin China
Brand Name YUCHIP
Certification CE,ROHS,FCC,EMC
Model Number OR-10D
Minimum Order Quantity 1sqm
Price Negotiable
Packaging Details Flight Case,Wooden Case,Strong Carton Box
Delivery Time 15-20 Working Days
Payment Terms T/T
Supply Ability 5000㎡/Month
Product Details
High Light

full color outdoor advertising led display

,

waterproof led display
Leave a Message
Product Description

Waterproof Outdoor Rental LED Display Hire , Led Matrix Display for Product Launches​







Quick Detail:





1, LED Brand: Epistar;

2, Power Supply: YHY or G-Energy;

3, Connector: Neutric and Weipu;

4, Cabinet: YUCHIP, die casting aluminum;

5, Cabinet Weight: 12.5kg/cabinet;

6, Installation Method: Both hanging up and on stand.







Description:





1, P10 outdoor rental LED displays is utilizing DIP346 LED chips;

2, PH10 LED displays rental cabient is ultra slim model;

3, Fast: Fast Lockers for quick assembly and dismantling

3, Movable: Flight Case Package for frequent movement from one site to next

4, Convenient: Hanging Up on truss and On Stand installation method

5, High Brightness: P10 LED panels is utilizing high brightness LED chips to reach up to 8000nits for daytime use, the LED panel will show clear and vivid picture even under direct sunshine;

6, High contrast raio at 4000:1 to ensure clear and vivid image and video color.







Applications:



Concerts

TV Studios

Private Parties

Fashion Shows

Product Launches

Press Conferences

Political Gatherings

Programe Live Broadcast







Specifications :



LED MODULE PARAMETER
Pixel pitch (mm) 10
Pixel configuration 1R1G1B
Encapsulation DIP346
Colors matches 6:3:1
Module resolution (pixels) 32 x 32
Module pixel 1024
Module size (mm) 320 x 320
LED CABINET SPECIFICATION
Cabinet size (mm) 640 x 640 x 100
Cabinet resolution (pixels) 64 x 64
Cabinet pixels (pixels) 4096
Cabinet material Aluminum
Cabinet weight (kg) 14.5kg
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2) 10000
Brightness(cd/m2) ≥8000 (adjustable)
Brightness adjusted 100 grade by software or by Auto-optic induced
View angle Horizontal 110°; Vertical 70°
Best viewing distance (m) ≥8m
Communication distance(m) <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km
Display work method Static
LED driving method Constant driving current
Color contrast ratio 1800:1
Gray Grade 16bit
Display Color 439, 804, 651, 110
Refresh Frequency (Hz) ≥600
Picture display method Intellective control technology , test-itself technology , correct technology, Synchronization
Control
Input signal DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting )
System operating WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level IP65
Working temperature(ºC) -20～+60
Stored temperature (ºC) -30～+80
Operation humidity(RH) 0-95%
Display Lifetime(hours) 10 years or more( natural environment)
100000 hours( ideal environment)
Maintenance Rear side
Working Voltage AC110 / AC220V±10% 47～63HZ
Out of controlled dot ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one)







Competitive advantages:



1, P10 1RGB LED Screens Rental is of most popular choose for its high resolution and cost effective compared with P6 Outdoor Rental LED Displays.

2. Stable quality: Professionally supplied LED screen to over 80 countries and installed thousands projects in 10 years;

3. Innovation: Carefully listen to customer need and create improved LED display products to support local LED sign market development;

4. Trusted service: Local cooperation distributors in Italy,Poland,Malaysia and Thailand; 24/7 LED experts online support; LED engineer on-site support;

5. Strong supply ability: 5000㎡ per month LED display production and regular products in stock for quick delivery;

5. Reasonable price: Profit back to customer for long term mutual development cooperation;

6, PH10 pixel pitch rental LED video walls is being widely used with its stable die casting aluminum structure and flight case package.



Waterproof Outdoor Rental LED Display Hire , Led Matrix Display for Product Launches 0Waterproof Outdoor Rental LED Display Hire , Led Matrix Display for Product Launches 1



Waterproof Outdoor Rental LED Display Hire , Led Matrix Display for Product Launches 2Waterproof Outdoor Rental LED Display Hire , Led Matrix Display for Product Launches 3
