Full Color Advertising High Brightness LED Display for Museum Entertainment Bar
Product Details
| High Light | high definition led display,led video display board |
||
|---|---|---|---|
Product Description
Full Color Advertising High Brightness LED Display for Museum Entertainment Bar
Quick Detail:
1, High brightness at 7000cd/㎡;
2, SMD3535;
3, IP65 waterproof;
4, LED Chips: Epistar;
5, LED Module: 192mm x 96mm;
6, LED Cabinet: 960mm x 960mm.
Description:
1, P6 Outdoor Full Color Advertising LED Display, as a high resolution outdoor LED display, is being choose more and more by advertising LED screens clients;
2, P6 Outdoor Advertising LED Display is utilizing high brightness Epistar LED chips to reach high brightness at 7000cd/㎡;
3, High brightness P6 outdoor LED screens insure a clear and vivid LED image display, even under direct sunshine light;
4, P6 LED displays outdoor is utilizing SMD3535 LED chips, the SMD LED panels makes big viewing angle at 140 degree both horizontal and vertically, audience from any direction could enjoye its shining advertising effect;
5, Outdoor LED screens P6 SMD3535 best view distance is above 5 meters, suit for LED advertising billboard project requiring short viewing distance;
6, P6 outdoor LED wall will lead the outdoor advertising LED screen trend for higher resolution.
Applications:
Airport Advertising LED displays
Train station Advertising LED displays
Entertainment Bar Advertising LED displays
Stadium Advertising LED displays
Museum Advertising LED displays
Car exhibition Advertising LED displays
Conference room Advertising LED displays
Shopping Mall Advertising LED displays
Street Advertising LED Billboard
Stores LED Advertising Display
Office Building LED advertising Screens
Roof Building Outdoor LED Display Screens
Specifications :
| LED MODULE PARAMETER | |
| Pixel pitch (mm) | 6 |
| Pixel configuration | 3 in 1 |
| Encapsulation | SMD3535 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 32 x 16 |
| Module pixel | 512 |
| Module size (mm) | 192 x 96 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 160 x 160 |
| Cabinet pixels (pixels) | 25600 |
| Cabinet material | Steel / Aluminum |
| Cabinet weight (kg) | 50kg / 40kg |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 27777 |
| Brightness(cd/m2) | ≥7000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 140°; Vertical 140° |
| Best viewing distance (m) | ≥5m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1, P6 Outdoor Advertising LED Screen is of high definition at 27777pixels/㎡ with more clear and vivid LED billboard advertising effect;
2, 5 meters best viewing distance, this guarantee a clear LED advertising display when viesing distance is quite near;
3, 140 degree viewing angle makes P6 outdoor LED screen suited not only for outdoor fixed installation LED screens, but also for rental LED wall projects, like stadim LED display;
4, P6 spare parts are of best quality components, like Epistar LED chips, MBI5024 IC driver, Meanwell power supply and Neutric power and signal connectors etc.;
5, High quality P6 outdoor LED advertising displays is manufactured under ISO9001-2008 quality management system, all products passed CE,RoHs,FCC,CCC certificates. EMC LED displays is available for most series LED screens;
6, All YUCHIP outdoor LED screen and indoor LED displays are with 3 years warranty.
