Sporting High Reresh Frequency Stadium LED Display P10 1RGB 2400HZ
Product Details
| High Light | sports perimeter led display,led digital display |
||
|---|---|---|---|
Product Description
Sporting High Reresh Frequency Stadium LED Display P10 1RGB 2400HZ
Quick Detail:
1, High refresh frequeny above 2400HZ;
2, LED Source: DIP346;
3, Meanwell power supply;
4, Module Size: 320mm x 320mm;
5, Cabinet Size: 960mm x 960mm;
6, High brightness up to 8000cd/㎡;
Description:
1. P10 sporting LED display scoreboard is utilizing 1RGB DIP LED lamp technology to deliver high brightness effect even under direct sunlight;
2. Sports LED scoreboard screen high refresh frequency to insure flickering free images and videos effect during live broadcast, and this point is highly important for sports LED screen projects;
3. P10 perimeter LED screens outdoor LED display scoreboards is using waterproof cabinet design of IP65 to realize waterproof,moisture proof etc for outdoor stadium environment use;
4. LED digital scoreboard software is specially designed for different sporting matches like basketball,soccer and baseball etc;
5, Electric LED scoreboard is presenting clear and vivid advertising image and video;
6, Stadium LED screens is of high contrast ratio at 4000:1 to present true and natural color LED screens;
Applications:
Stadium LED Display
Perimeter LED Screen
Football Stadium LED Screen
Football Perimeter LED Display
Basketball Stadium LED Displays
Soccer LED Display
Baseball Stadium LED Display Screens
Sporting Stadium LED Video Display
Sports Perimeter LED Screen
Sports Club LED Display
LED Score Boards
LED Score Display
LED Digital Scoreboard
Perimeter LED Screen
Football Stadium LED Screen
Football Perimeter LED Display
Basketball Stadium LED Displays
Soccer LED Display
Baseball Stadium LED Display Screens
Sporting Stadium LED Video Display
Sports Perimeter LED Screen
Sports Club LED Display
LED Score Boards
LED Score Display
LED Digital Scoreboard
Specifications :
| LED Module Parameter | |
| Pixel pitch (mm) | 10 |
| Pixel configuration | 1R1G1B |
| Encapsulation | DIP346 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 32 x 32 |
| Module pixel | 1024 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 96 x 96 |
| Cabinet pixels (pixels) | 9216 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 55 |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 10000 |
| Brightness(cd/m2) | ≥8000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 110°; Vertical 70° |
| Best viewing distance (m) | ≥8m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥2400 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video procrssor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1, P10 sports LED screen brightness automatic adjustment. By Lisn multi function card, the LED score boards can sensor local brightness, humidty and temperature etc information;
2, In daytime, sports LED screen will show high bightness for clear and vivid image / video, and in night time sporting LED screens will show lower brightness for comfortable watching;
3, P10 LED scoreboard is of high resolution at 10000pixels/㎡;
4, P10 LED screen, the best view distance is above 8 meters;Audience/potential consumers people passed by would enjoy a clear image that standing above 8 meters;
5, Outdoor P10 LED screens is utilizing high brightness Epistar LED chips to reach up to 8000cd/㎡. The P10 LED video displays present a clear and vivid image, even under direct sunshine;
6, P10 perimeter LED display scoreboards seamless connection: 320mm x 320mm large size LED module makes LED display seamless connection in one cabinet;
