P5mm Indoor Mobile Rental LED Display Board For Stage Background

  • img.alt
  • img.alt
  • img.alt
Place of Origin CHINA
Brand Name YUCHIP
Certification CE,ROHS,FCC,EMC
Model Number P10MM
Minimum Order Quantity 1sqm
Price Negotiable
Packaging Details Flight Case,Wooden Case,Strong Carton Box
Product Details
High Light

led panel display

,

led full color screen
Leave a Message
Product Description

Specifications

P5mm indoor mobile rental led display board for stage background
1.Large viewing angle;
2.Perfect color mixing effect

P5mm indoor mobile rental led display board for stage background



Led sign board:
1. High intensity,No mosaic
2. Low power consumption
3.Competitive price, super design
4. CCC,CE,ROHS,ISO



Features:

LED Display screen for stage rental service design for stage rental company who need quickly fixing the screen in stage, the important feature is all frame made aluminous to reduce the weight, and add lock in the side of frame for air-handing instal, also all rental screen should be made by SMD 3 in 1 LED to show very nearly distance view.

The control system includes video processer, it can be work with laptop, DVD player, camera digital input, S-Video, CRV and so on. It's a idea for stage to make it easy instal and play.



Parameters:



Technical Specification:

PH5mm 1R1G1B full-color indoor indoor rental Led Display

Pixel Configuration

1R,1G,1B

Physical/Real pixel pitch(mm)

5

Pixel density(dots/sqm)(physical/real)

40000

Calibrated Brightness

8000 nits(adjustable)

Color temperature

3,500° — 9,500° K(adjustable)

Contrast ratio

4,000:1

Brightness Adjustment

100 grade auto-adjustment



View angle(degree)(50% brightness)

Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center)

Color Capability

4.4 trillion

Interface port

DVI interface(DVI connector)

 Input signal

Video: PAL/NTSC Optioned: VGA, video, DVD,TV

Protection grade

IP65 front side/IP54 backside

Operating temperature(Celsius degree)

-20~+55'

Storage temperature(Celsius degree)

-30~+55'

Operation Humidity(RH)

0-95%

Storage Humidity(RH)

0-99%

Lifetime(hours)(50% brightness)

100,000 hours

Servicing

Front and Back

Power supply

100-240V/50-60HZ

LED Drive

1/8 Constant driving

Power consumption(W/sqm):Maximum

1800

Power consumption(W/sqm):Average

630-810

Module Configuration(Pixels quantities of the module)

length

32

height

 32



Module Dimensions(mm)

length

160

height

160

Cabinet Configuration(standard)(module quantities of the cabinet)

length

4

height

6

Cabinet Dimensions(standard)(mm)

length

960

height

960



P5mm Indoor Mobile Rental LED Display Board Cabinet:



P5mm Indoor Mobile Rental LED Display Board For Stage Background 0

P5mm Indoor Mobile Rental LED Display Board Prat Of Case:



P5mm Indoor Mobile Rental LED Display Board For Stage Background



P5mm Indoor Mobile Rental LED Display Board For Stage Background Case
