P1.56 indoor led display wall HD LED screen for indoor stage video wall usage
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Data Refresh Rate | ≥2880HZ | Cabinet Size(W X H X D) | 400x300mm |
|---|---|---|---|
| Screen Brightness | ≥1000cd/m2 | Module Size | 200 X 150mm |
Product Description
High Definition P1.56 indoor led display wall HD LED screen
1.Clear picture without flicker and distortion
2. Multiform file formats, such as VGA, Video, AVI, MOV, MPG, DAT, VOB and so on are comprehensive
3. Low consumption, stable performance, highly durable
4. High brightness & broad viewing angle, brightness can be adjusted automatically or manually
5. 2 years warranty, easy to install & maintenance
6. CE, ROHS, FCC
1.56mm indoor led display wall HD LED screen Parameters:
|
Item |
Specification |
|
|
Pixel |
Physical pixel pitch: 1.56 mm |
|
|
Pixel configuration: 1R1PG1PB |
||
|
Module |
Module resolution:128x96 pixels |
Module size: 200 x 150mm |
|
Cabinet |
Cabinet resolution:256x192pixel |
Cabinet size: 400 x 300 x 75mm |
|
Cabinet density:49152pixels |
Module Qty: 4pcs = 2(w) x 2(h) |
|
|
Material: Iron |
Weight: 5.8Kg |
|
|
Average power: 80W |
Max power consumption: 150W |
|
|
Electricity parameter |
Brightness: 800 - 1100 nits |
|
|
Brightness adjusted: 100 grade by software, or by Auto-optic induced |
||
|
Color processing: 16bit |
||
|
Display color: 280 trillion |
||
|
Color temperature(k): 5000 — 9500 (choice by user) |
||
|
Physical density: 409800 pixels/sqm |
||
|
Whole display flatness: ≤ 1mm juncture |
||
|
Best view distance: ≥ 3m |
||
|
Best view angle: Horizontal ±80°, Vertical ±80° |
||
|
Storage temperature: -35℃ ~ +85℃ Working temperature: -20℃ ~ +50℃ |
||
|
Driving method: Constant driving current Scan: 1/32 |
||
|
Refresh frequency: ≥ 1200Hz |
||
|
Frame rate: ≥ 60Hz |
||
|
Humidity(RH): ≤ 90 ~ 95% |
||
|
Protection grade: IP31 |
||
|
Working Voltage: DC 5V |
||
|
Power supply: AC110 / 220V, 50/60Hz |
||
|
Average power consumption: 400 w/sqm |
||
|
Max power consumption: 1100 w/sqm |
||
|
MTBF: 10000 hours |
||
|
Screen lifetime: 100000 hours |
||
|
Control system |
Signal interface: DVI |
|
|
Communication distance: Internet cable: ≤ 120m Fiber cable: 1000m |
||
|
Signal transfer mode: Pixels to pixels display synchronized |
||
Application:
Widely used in TV studio hall, military command centers, control centers, clubs, video conference center, banquet hall, and star hotels etc.
Why Choose us?
YUCHIP has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
Pre-sale service:
1. Reply enquiries in 24 hours.
2. Market research and forecast for customer.
3. Provide unique and professional solutions based on customer's requirement.
4. Data sheet and samples offer.
5. Other services, such as special packing design, factory visiting and so on.
