Outdoor P6 High Definition Outdoor Led Panel Display / Advertising Led Display
Product Details
| High Light | electronic led display,digital signage display |
||
|---|---|---|---|
Product Description
Outdoor P6 High Definition Outdoor Led Panel Display / Advertising Led Display
Quick Detail:
1, Both front and rear maintenance;
2, 1RGB DIP246;
3, High brightness up to 8000cd/sqm;
4, High resolution:22477 pixel pitches per square meters;
5, High contrast ratio at 4000:1;
6, IP65 waterproof for outdoor use;
Description:
1. P6 outdoor LED screen is of high resolution for outdoor LED billard project;
2. P6.67 outdoor full color dual maintenance LED display is automatic brightness adjustment for day and night use to save energy and deliver a comfortable advertising effect;
3. P6.67 DIP246 dual maintenane LED screen is delivering high quality image and video presentation for large size LED billboards advertising use;
4. P6.67 front accessible LED sign is of high resolution at 22477 pixels/㎡ for fixed installation outdoor LED screens;
5. Outdoor LED display P6 is of high brightness to deliver a clear image and video even under direct sunshine;
6. Outdoor P6 LED display is utilizing LED control software like Linsn,Nova,DBstar,ZQEC etc.
Applications:
Easy Maintenance LED Signage
Front Maintenance LED Billboard
Front Accessible LED Signs
Front Maintenance Digital LED Sign
LED Digital Sign Front Maintenance
Electronic LED Sign Front Accessible
Front Maintenance LED Sign
Front Open LED Display
Dual Maintenance LED Screen
Front and Back Maintenance LED Display Screen
Front and Rear Maintenance LED Panel
Specifications :
| LED MODULE PARAMETER | |
| Pixel pitch (mm) | 6.67 |
| Pixel configuration | 1R1G1B |
| Encapsulation | DIP246 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 48 x 48 |
| Module pixel | 2304 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 144 x 144 |
| Cabinet pixels (pixels) | 20736 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 50kg |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 22477 |
| Brightness(cd/m2) | ≥7500 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 140°; Vertical 140° |
| Best viewing distance (m) | ≥6m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/6 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥2800 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1. P6 outdoor LED screens is utilizing DIP246 LED lamp with stable quality and good waterproof effect;
2, Outdoor P6 LED video display is of high contrast ratio at 4000:1 to present real and natural color;
3. High brightness up to 8000cd/㎡,and special requirement LED screen projects can reach 10,000nits;
4. There is no screw between LED modules and LED panel for fast and easy maintenance;
5. Suitable for LED display projects that limit installation site back side space;
6. Space saving:For installation site that backside space limited,it's a perfect option of this dual maintenance which allows front maintenance and not need backside space;
