High Definiton Outdoor Led Video Display P1.9 Led Video Wall Rental
Product Details
| High Light | outdoor led video display,led video wall rental |
||
|---|---|---|---|
Product Description
Product Description
1.HD1.6 has exceptional display quality even when brightness is reduced to 20%.The so-called seamless, thinnest, super-thin and barely seamless marketing can never change the fact that there are still gaps between cabinets, while Chipshow’s fast-connector makes the real seamless splicing possible.
2.6:9 design. Cabinet's 16:9 resolution is specialized for command center. Perfect replacement for LCD display.Die cast aluminum cabinet, guarantee you a flat and seamless screen.Good uniformity. Dot-to-dot correction technology provide you pure image with great gradation.
3.Modular design. Efficient and low cost installment and maintenance. Patented cooling system, fanless, non-noise, energy-saving and eco-friendly.High reliability. Redundant N+1 power system, dual signal hot backup. Auto-switch and warn malfunction.
4.Vertical/horizontal: 160°/160°, broadcast-level color gamut, CT and brightness adjustable,more appropiate for long-time watching.
| LED MODULE PARAMETER | ||||
| Pixel pitch (mm) | 1.9 | |||
| Pixel configuration | SMD1010 | |||
| Encapsulation | 3 in 1 | |||
| Module resolution (pixels) | 104 x 156 | |||
| LED CABINET SPECIFICATION | ||||
| Module size | 200 x 300 | |||
| Cabinet size (mm) | 400 x 300 x 80 | |||
| Cabinet size (mm) | 400 x 300 x 80 | |||
| Cabinet resolution (pixels) | 208 x156 | |||
| Cabinet pixels (pixels) | 32448 | |||
| Cabinet material | Die casting aluminum | |||
| Cabinet weight (kg) | 5.2 | |||
| LED DISPLAY SPECIFICATION | |||||||
| Cabinets qty in display | 15(W) x 13(H) = 195 | ||||||
| Display resolution(dots) | 3120(W) x 2028(H) = 6327360 | ||||||
| Pixel density(pixel/m2) | 270400 | ||||||
| Brightness(cd/m2) | ≥2000 (adjustable) | ||||||
| Brightness adjusted | 256 grade by software or by Auto-optic induced | ||||||
| View angle | Horizontal 140°; Vertical 140° | ||||||
| Best viewing distance (m) | ≥1.5m | ||||||
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km | ||||||
| Display work method | 1/26 Scan | ||||||
| LED driving method | Constant driving current | ||||||
|
|||||||
| Gray Grade | 16bit | ||||||
| Display Color | 439, 804, 651, 110 | ||||||
| Refresh Frequency (Hz) | ≥2400 | ||||||
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control | ||||||
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video procrssor converting ) | ||||||
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. | ||||||
| Front/Rear IP Level | IP43 | ||||||
| Working temperature(ºC) | -20～+40 | ||||||
| Stored temperature (ºC) | -40～+80 | ||||||
| Operation humidity(RH) | 0-95% | ||||||
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
||||||
| Maintenance | Rear side | ||||||
| Working Voltage | AC110 / AC220V±10% 47～63HZ | ||||||
| Power consumption | Max: 750W/㎡ ; Ave:300W/㎡ | ||||||
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) | ||||||
High Definiton Video Indoor Led Display P1.9 Led Screen Aging:
P1.9 hd led video display led panel Application places
Ideal for auditorium, conference room, banquet hall and exhibition presentations, traffic, studio, command and monitor system.
1)Your inquiry related to our products or price will be replied in 24hrs
2)OEM&ODM,any your customized lightings we can help you to design and put into product
3)Distributoership are offered for your unique design and some our current models
4)Protection of your sales area,ideas of design and all your private information
Trade Terms
1.Payment:T/T,30% deposits before production,70% balance to be paid before dleiverying
2.Shipping freight are quoted under your requests
3.Shipping port:ShenZhen,Mainland China
4.MOQ:1pc
