Ultra HD LED TV Screen / Home Theatre led video wall panelS Perfect Performance

  • img.alt
  • img.alt
  • img.alt
Place of Origin China
Brand Name YUCHIP
Certification CE,ROHS,FCC,EMC
Model Number P2.5
Minimum Order Quantity 1sqm
Price Negotiable
Packaging Details Flight Case,Wooden Case,Strong Carton Box
Supply Ability 5000㎡/Month
Product Details
Pixel Pitch (mm) 2.5 Pixel Configuration SMD2121
Module Size 200 X 300
High Light

outdoor led video display

,

led video wall rental
Leave a Message
Product Description

Ultra HD LED TV Screen / Home Theatre led video wall panelS Perfect Performance



High-End Small Pixel Pitch HD LED Wall P2.5 P1.9 P1.6
HD Large LED Wall help you catch more eyes on advertising.
Especially for high end conference, meeting, exhibition, trade shows. It does not only displays high clear images, flashes and videos of your product.
But also shows your company economic power to your customers.
It's high resolution also enables led wall become the new replacement visual equipment in cinema.



LED MODULE PARAMETER
Pixel pitch (mm) 2.5
Pixel configuration SMD2121
Encapsulation 3 in 1
Module resolution (pixels) 80*120
LED CABINET SPECIFICATION
Module size 200 x 300
Cabinet size (mm) 400 x 300 x 80
Cabinet resolution (pixels) 160*120
Cabinet pixels (pixels) 19200
Cabinet material Die casting aluminum
Cabinet weight (kg) 5.2
LED DISPLAY SPECIFICATION
Cabinets qty in  display 2(W) x 2(H) = 6
Display resolution(dots) 480(W) x 240(H) = 11520
Pixel density(pixel/m2) 160000
Brightness(cd/m2) ≥2000 (adjustable)
Brightness adjusted 256 grade by software or by Auto-optic induced
View angle Horizontal 140°; Vertical 140°
Best viewing distance (m) ≥1.5m
Communication distance(m) <100meter by Internet Cable(without Relay;            Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km
Display work method 1/26 Scan
LED driving method  Constant driving current
Color contrast ratio
　
Gray Grade 16bit
Display Color 439, 804, 651, 110
Refresh Frequency (Hz) ≥2400
Picture display method Intellective control technology , test-itself technology , correct technology, Synchronization Control
Input signal  DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video procrssor converting )
System operating  WINDOWS 98,  WINDOWS 2000,  WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP Level IP43
Working temperature(ºC) -20～+40
Stored temperature (ºC)  -40～+80
Operation humidity(RH)  0-95%
Display Lifetime(hours) 10 years or more( natural environment)
100000 hours( ideal environment)
Maintenance Rear side
Working Voltage AC110 / AC220V±10%  47～63HZ
Power consumption Max: 750W/㎡ ; Ave:300W/㎡
Out of controlled dot ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one)



Indoor HD Led Video Wall Case:

Ultra HD LED TV Screen / Home Theatre led video wall panelS Perfect Performance 0



FAQ

1. How can i place an order?
Please provide the details of your requirements as clear as possible. So we can send you the offer at the first time. For designing or further discussion, it is better to contact us with Skype/email /phone, in case of any delays.

2. What kind of display we provide?
We have indoor/outdoor/led curtain/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display for you choose.

3. What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 5 days

4.How about the warranty ?
We have two years warranty.
