Giant video wall hd Led Outdoor Advertising Board module pixel pitch 1.6mm
Product Details
| Pixel Pitch | 1.6 Mm | Brightness | 400cd/m2 |
|---|---|---|---|
| Cabinet Thickness | 77mm | ||
| High Light | outdoor led video display,led video wall rental |
||
Product Description
Giant video wall hd Led Outdoor Advertising Board module pixel pitch 1.6mm
indoor full color hd small display HD1.6 led module pixel pitch 1.6mm
1. High gray scale and high refresh rate while low brightness;
2. Wide viewing angle, details perfectly showed;
3. Seamless connection, simple but fashionable appearance;
4. Energy conservation and environment protection, saving 15% of energy compared with traditional cabinets;
5. Adjustable brightness (300-800nits).
Indoor HD LED Display P1.6 Parameters:
|
Model Number |
pixel pitch 1.6mm |
|
Description |
Die-casting Aluminum cabinets with hanging function |
|
Application |
Indoor use, AV rental |
|
Pixel configuration |
SMD1010 Black led |
|
Pixel pitch |
1.6mm |
|
Cabinet pixel resolution |
W 240 x H 180pixels |
|
Cabinet dimension |
W: 400mm, H: 300mm, T: 63mm |
|
Module size |
W: 200mm, H: 100mm |
|
Module pixel resolution |
W 120 x H 60 pixels |
|
Pixel density |
360,000dots/sqm |
|
Minimum viewing distance |
2m |
|
Brightness |
800nits |
|
Grey scale |
14 bits |
|
Color Number |
68.7194billion |
|
Display Mode |
Synchronous with video source |
|
Data refresh rate |
≥2880HZ |
|
Driver IC |
MBI5153 |
|
LED drive |
1/30 scanning, constant current |
|
Control system type |
Novastar |
|
Control software name |
Nova studio |
|
Viewing angle |
Vertical 140° Horizontal 140° |
|
Temperature range |
-20℃ to +60℃ |
|
Ambient Humidity |
10%-99% |
|
Service access |
Rear |
|
Cabinet weight |
4.8kg |
|
Power Consumption |
Max: 100 w/pcs; Average : 50w/pcs |
|
Protection Level |
IP43 |
|
Lifetime to 50% brightness |
75,000hr |
|
LED Failure Rate |
<0,00001(Led display line standard <0,0001) |
|
MTBF |
> 100.000 hours |
|
Input power cable |
AC110V to 220V |
|
Signal input |
DVI |
|
Certification |
CE, ROHS, FCC marked |
|
Warranty |
2 Years quality warranty |
