P1.9 Indoor Video Wall Ultra HD Led Screen TV high Brightness
Product Details
| Pixel Configuration | SMD1010 Black Led | Data Refresh Rate | ≥2880HZ |
|---|---|---|---|
| Color Temperature | 6500 | ||
| High Light | outdoor led video display,led video wall rental |
||
Product Description
P1.9 Indoor Video Wall Ultra HD Led Screen TV high Brightness
Seamlessness: Die-casting aluminum panel, high-precision design and CNC processing minimize the error within 0.05mm.
Long lifespan:
Low-voltage power supply with high-efficiency causes little temperature rise, which helps to prolong the life of LED display in stable use.
Perfect Image: No flicker, no brightline or darkline ensures the LED display to take on more perfect image.
Industrialized Production: Patented technology, independent die sinking, precise welding and automatic processing all take the lead in LED industry.
Core Advantages:
Color Uniformity: The LED display would present uniform color at all times with low power consumption and low temperature rise.
No Blackout during Use: Reliable communication-level power supply and rational power distribution system lead to stable and safe operation.
Safe Maintenance: It supports hot swapping, which is more safe and convenient for maintenance personnel.
Indoor HD LED Display P1.9 Parameters:
|
Parameter |
Unit |
Value |
|
Pitch |
mm |
1.923 |
|
Brightness |
nits |
1,200 |
|
Color temperature |
deg. K |
6,500 |
|
Viewing angle -Horizontal (50% brightness) |
deg. |
140(-70 ~ +70) |
|
Viewing angle - Vertical (50% brightness) |
deg. |
140(-70 ~ +70) |
|
Panel weight |
kg |
5 |
|
Panel width |
mm |
400 |
|
Panel height |
mm |
300 |
|
Panel depth |
mm |
92 |
|
Panel area |
sq. m. |
0.12 |
|
Panel material |
|
Epoxy paint coated Aluminum |
|
Panel Mode |
|
Die-Cast rental |
|
Operating temperature range |
deg. C |
-20 to +60 |
|
Humidity operating |
RH |
10% ~ 60% |
|
Pixel type and configuration |
R/G/B |
3-in-1 SMD |
|
Resolution per panel |
|
208x156 |
|
Dot per panel |
|
32,448 |
|
Dot per sq. meter |
|
270,422 |
|
LED per sq. meter |
|
270,422 |
|
Recommended minimum viewing distance |
m |
1.46 |
|
Recommended best viewing distance |
m |
2-18m |
|
Colors |
|
|
|
Grey scale (linear) |
Levels |
65,536 |
|
Brightness control |
Levels |
256 |
|
Contrast ratio |
|
2,000:1 |
|
Processing depth |
bit |
16 |
|
Video frame rate |
Hertz |
60 |
|
Display refresh rate |
Hertz |
1,200 |
|
Input voltage (nominal) |
VAC |
110 to 240 |
|
Input power frequency |
Hertz |
50 to 60 |
|
Input power (max) |
Watts / panel. |
120 |
|
Input power (typical) |
Watts / panel. |
48 |
|
Lifetime (50% brightness) |
Hours |
≥100,000 |
|
Red wavelength (dominant) |
nm |
620~625 |
|
Green wavelength (dominant) |
nm |
520~525 |
|
Blue wavelength (dominant) |
nm |
470~475 |
|
Multimedia data format |
|
DVI,MPG,AVI,WMV,RM etc. |
|
Data interconnection |
|
UTP Cat 5/Optical Fiber |
|
Mounting system |
|
Hanging/Fixed |
P1.9 Indoor HD LED Display HD Led Video Wall Ultra HD LED TV Screen Case:
Application:
Widely used in TV studio hall, military command centers, control centers, clubs, video conference center, banquet hall, and star hotels etc.
Our Services:
1. Your enquiry will be replied in 24 working hours.
2. Experienced staffs answer all your query in fluent English and Russian.
3. Customized design is available,OEM & ODM are welcomed.
4. Exclusive and unique solution can be provided by our well-trained and professional engineers and staffs.
5. Area distributor enjoys special discount and protection of sales area.
6. Your visit will warmly welcome in anytime.
7. 2 Years guarantee. Only charge for cost of repair after 2 years.
8. YUCHIP assists with trainning and technical support for clients in the factory. This service is free of charge.
9. YUCHIP offer oversea technical support by well-trained engineers if clients required. The relevant costs charge by clients.
