Comercial smd led video panel / large screen display solutions super HD
Product Details
| Minimum Viewing | Distance 2m | Pixel Pitch | 1.6mm |
|---|---|---|---|
| LED Drive | 1/30 Scanning | Service Access | Rear |
| High Light | outdoor led video display,led video wall rental |
||
Product Description
Comercial smd led video panel / large screen display solutions super HD
1) High and adjustable brightness can meet the demands of the changing requirement of Customer in different environments.
2) No mosaic due to excellent flatness and nice uniformity of light-emitting.
3) Wide viewing angles and the horizontal angle can reach 140° , The images effect will not change largely in the range.
4) Good heat dissipation capability because of the unique design of vent fan.
5) Environmental-friendly and energy-saving.
Indoor HD LED Display P1.6 Parameters:
|
Model Number |
pixel pitch 1.6mm |
|
Description |
Die-casting Aluminum cabinets with hanging function |
|
Application |
Indoor use, AV rental |
|
Pixel configuration |
SMD1010 Black led |
|
Pixel pitch |
1.6mm |
|
Cabinet pixel resolution |
W 240 x H 180pixels |
|
Cabinet dimension |
W: 400mm, H: 300mm, T: 63mm |
|
Module size |
W: 200mm, H: 100mm |
|
Module pixel resolution |
W 120 x H 60 pixels |
|
Pixel density |
360,000dots/sqm |
|
Minimum viewing distance |
2m |
|
Brightness |
800nits |
|
Grey scale |
14 bits |
|
Color Number |
68.7194billion |
|
Display Mode |
Synchronous with video source |
|
Data refresh rate |
≥2880HZ |
|
Driver IC |
MBI5153 |
|
LED drive |
1/30 scanning, constant current |
|
Control system type |
Novastar |
|
Control software name |
Nova studio |
|
Viewing angle |
Vertical 140° Horizontal 140° |
|
Temperature range |
-20℃ to +60℃ |
|
Ambient Humidity |
10%-99% |
|
Service access |
Rear |
|
Cabinet weight |
4.8kg |
|
Power Consumption |
Max: 100 w/pcs; Average : 50w/pcs |
|
Protection Level |
IP43 |
|
Lifetime to 50% brightness |
75,000hr |
|
LED Failure Rate |
<0,00001(Led display line standard <0,0001) |
|
MTBF |
> 100.000 hours |
|
Input power cable |
AC110V to 220V |
|
Signal input |
DVI |
|
Certification |
CE, ROHS, FCC marked |
|
Warranty |
2 Years quality warranty |
indoor full color hd small display HD led module pixel pitch Case:
Good service
1.Offer one year warranty. Will send spare parts to fix for free if the products got faulty during warranty period.
2.Will offer one more AD board for spare part for order quantity get to 30pcs.
3.Will offer 1% spare parts for order quantity get to 100pcs. Spare parts including AD board, PSU, all cables and accessories except LCD screen and housing.
4.Accept OEM and ODM order, can silk print customer's logo on the product, can add customer's opening up logo.
5. Can send engineer to help installation if customer request, but customer pay for flight ticket and accomodation.
