Road Show LED Screen Advertising , P20 Led Outdoor Display Full Color
Product Details
| High Light | full color led signs outdoor,outdoor full color led display |
||
|---|---|---|---|
Product Description
Road Show LED Screen Advertising , P20 Led Outdoor Display Full Color
Quick Detail:
1, 2500pixels/㎡;
2, Best view distance above 18 meters;
3, LED Chips: Epistar
4. LED Source: DIP 346;
5. Module: 320mm x 320mm;
6. IP65, waterproof.
Description:
1, Road Show LED Screen Advertising is utilizing internal signal and power connection for stable connection;
2. P20 outdoor LED billboard is cost effective,expecially suitable for large size LED sign billboards;
3. YUCHIP is utizling Epistar LED chips for high quality image and video presentation for large size LED billboards advertising use;
4. Enough brightness to deliver a clear image and video even under direct sunshine;
5. Remote control help to realize one computer control numbers LED screen timely;
6. Outdoor LED displays automatic brightness adjustment to present high brightness image under direct sunshine; In night time outdoor LED screen brightness lower down for confortable watching;
6. Remote control help to realize one computer control numbers LED screen timely;
Applications:
On roof of building Full Color LED Display
Mounted on buildingFull Color LED Display
Put on steel pole Full Color LED Display
Cross bridge information Full Color LED Display
Shopping Mall Full Color LED Display
Commercial Advertising Full Color LED Display
Church Full Color LED Display
Road Show Full Color LED Display
High Speed Way Full Color LED Display
Specifications :
| LED Module Parameter | |
| Pixel pitch (mm) | 20 |
| Pixel configuration | 1R1G1B |
| Encapsulation | DIP346 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 16 x 16 |
| Module pixel | 256 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 48 x 48 |
| Cabinet pixels (pixels) | 2304 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 50 |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 2500 |
| Brightness(cd/m2) | ≥8000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 110°; Vertical 70° |
| Best viewing distance (m) | ≥18m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Power consumption | Max: 850W/㎡ ; Ave:350W/㎡ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1. Full color LED display is eye catching active advertising effect deliver to more audience and gain more revenues;
2. P20 Outdoor LED billboard is being widely choose for large size outdoor LED signs projects;
3. Standard LED cabinet of IP65,waterproof and dustproof;
4. High brightness up to 8000cd/㎡,and special requirement LED screen projects can reach 10,000nits;
5, The LED billboards present clear vivid image and video even under direct sunshine;
6, P20 outdoor full color LED media display is engery saving 30% by 4.2V current design.
