P8 DIP246 Truck LED Display , Advertising Mobile Led Screen Trailer

Certification CE,ROHS,FCC,EMC
Model Number OT-8D
Minimum Order Quantity 1sqm
Price Negotiable
Packaging Details Flight Case,Wooden Case,Strong Carton Box
Delivery Time 15-20 Working Days
Payment Terms T/T
Supply Ability 5000㎡/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Highlight

mobile led screen

,

mobile led display trailer

Leave a Message
Product Description

P8 DIP246 Truck LED Display , Advertising Mobile Led Screen Trailer​



Quick Detail:


1. DIP246 LED;
2, LED Chips: Epistar
3. Module: 320mm x 320mm;
4. Cabinet: 960mm x 960mm x 150mm;
5. IP65, waterproof;
6. 4 sets fast lockers equipped on each cabinet.


Description:

1. High level anti-shake: this is very important for movable LED screen;
2. LED screen truck rental has generator inside the truck to support move freely to any site needed without power supplying issue;
3. To insure truck LED screen is of high grade anti-shake,before the shipment, each cabinet has to pass a strict anti-vibration test to prevent the damages caused by any improper transportation;
4. For better protecting truck LED displays, it's always packaged with an independent anti-vibration flight case for a further protection to the display;
5. Truck LED screen provides MINI multimedia control room which supports multiple formats of the input mode,can use GPRS,3G wireless control system;
6. Truck LED display is utilizing energy saving LED display solution, and this feacutre brings truck LED screen big advantage in mobile LED billboard use.


Applications:

Truck LED Display
Truck LED Screen
Trailer Mounted LED Display
Trailer Mounted LED Screen
LED Display Truck Rental
Mobile Truck LED Display
Movable LED Screens
LED Screen Trailer
LED Display Trailer



Specifications :

LED Module Parameter
Pixel pitch (mm)8
Pixel configuration1R1G1B
EncapsulationDIP246
Colors matches6:3:1
Module resolution (pixels)40 x 40
Module pixel1600
Module size (mm)320 x 320
LED CABINET SPECIFICATION
Cabinet size (mm)960 x 960 x 150
Cabinet resolution (pixels)120 x 120
Cabinet pixels (pixels)14400
Cabinet materialSteel
Cabinet weight (kg)50
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2)15625
Brightness(cd/m2)≥8000 (adjustable)
Brightness adjusted100 grade by software or by Auto-optic induced
View angleHorizontal 110°; Vertical 70°
Best viewing distance (m)≥7m
Communication distance(m)<100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m; Single mode
fiber cable < 20km
Display work method1/4 Scan
LED driving methodConstant driving current
Color contrast ratio1800:1
Gray Grade16bit
Display Color439, 804, 651, 110
Refresh Frequency (Hz)≥1000
Picture display methodIntellective control technology , test-itself technology , correct technology, Synchronization
Control
Input signalDVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting )
System operatingWINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP LevelIP65
Working temperature(ºC)-20~+60
Stored temperature (ºC)-30~+80
Operation humidity(RH)0-95%
Display Lifetime(hours)10 years or more( natural environment) 100000 hours( ideal environment)
MaintenanceRear side
Working VoltageAC110 / AC220V±10% 47~63HZ
Power consumptionMax: 900W/㎡ ; Ave:400W/㎡
Out of controlled dot≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave
length are both >10% depart to the normal one)






Competitive advantages:

1, High resolution: P8 LED display is mostly used as high resolution outdoor LED screens;
2, Movable: truck LED screen is convenient to move from one site to next;
3, Fast investment earning back, as truck LED display is of frequent and convenient use for events, so it can be used more times in a limited time and earn more revenue;
4, Self-power supplying: Each mobile truck LED screen is equipped with noiseless generator and this enables truck mobile LED screen park any area without power supply limit;
5, P8 truck LED display is of high brightness to deliver a clear image and video even under direct sunshine;
6, Unlimited communication distance: P8 truck LED display is utilizing asynchronous control system, also 3G and GPRS synchronous control system is supported;
