High resolution P10 Mobile Truck Led Screen / Led Full Color Display
Product Details
| High Light | mobile led screen,truck mounted led screen |
||
|---|---|---|---|
Product Description
High resolution P10 Mobile Truck Led Screen / Led Full Color Display
Quick Detail:
1. High resolution of 10000pixels/㎡;
2. IP65 waterproof;
3. Noiseless generator equipped;
4, LED Chips: Epistar
5. Module: 320mm x 320mm;
6. Cabinet: 960mm x 960mm x 150mm;
Description:
1. P10 truck LED display screen provides MINI multimedia control room which supports multiple formats of the input mode,can use GPRS,3G wireless control system;
2. P10 truck LED can also use asynchronous control sytem which not require internet cable;
3. Truck LED display is utilizing energy saving LED display solution, and this feacutre brings truck LED screen big advantage in mobile LED billboard use.
4. High level anti-shake: this is very important for movable LED screen;
5. LED screen truck rental has generator inside the truck to support move freely to any site needed without power supplying issue;
6.To insure truck LED screen is of high grade anti-shake,before the shipment, each cabinet has to pass a strict anti-vibration test to prevent the damages caused by any improper transportation;
Applications:
Truck LED Display
Truck LED Screen
Trailer Mounted LED Display
Trailer Mounted LED Screen
LED Display Truck Rental
Mobile Truck LED Display
Movable LED Screens
LED Screen Trailer
LED Display Trailer
Specifications :
| LED Module Parameter | |
| Pixel pitch (mm) | 10 |
| Pixel configuration | 1R1G1B |
| Encapsulation | DIP246 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 32 x 32 |
| Module pixel | 1024 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 96 x 96 |
| Cabinet pixels (pixels) | 9216 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 50 |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 10000 |
| Brightness(cd/m2) | ≥8000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 110°; Vertical 70° |
| Best viewing distance (m) | ≥8m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Power consumption | Max: 900W/㎡ ; Ave:400W/㎡ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1, P10 truck LED display is of high brightness to deliver a clear image and video even under direct sunshine;
2, High resolution: P10 LED display is mostly used as high resolution outdoor LED screens;
3, Movable: truck LED screen is convenient to move from one site to next;
4, Self-power supplying: Each mobile truck LED screen is equipped with noiseless generator and this enables truck mobile LED screen park any area without power supply limit;
5, Unlimited communication distance: P8 truck LED display is utilizing asynchronous control system, also 3G and GPRS synchronous control system is supported;
6, Fast investment earning back, as truck LED display is of frequent and convenient use for events, so it can be used more times in a limited time and earn more revenue;
