Trailer LED Screen Rental High Resolution P10 Mounted LED Display

Certification CE,ROHS,FCC,EMC
Model Number OT-10D
Minimum Order Quantity 1sqm
Price Negotiable
Packaging Details Flight Case,Wooden Case,Strong Carton Box
Delivery Time 15-20 Working Days
Payment Terms T/T
Supply Ability 5000㎡/Month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Highlight

truck mounted led screen

,

mobile led display trailer

Leave a Message
Product Description

Trailer LED Screen Rental High Resolution P10 Mounted LED Display​



Quick Detail:


1. High resolution of 10000pixels/㎡;
2. Module: 320mm x 320mm;
3, Anti-shake;
4, Anti-thunder;
5, Mobile movable;
6, Noiseless power generator equipped.



Description:

1. P10 trailer LED screen support asynchronous control sytem like Xixun,Nova star, also support synchronous control system like Linsn,Nova and ZDEC etc;
2. Trailer LED display P10 is utilizing energy saving LED display solution, and this feacutre brings truck LED screen big advantage in mobile LED billboard use;
3. Trailer LED screen is of high level anti-shake: this point is very important for movable LED screen. All the truck LED screen must pass our anti-viration test before shipment;
4. Trailer LED screen is equipped generator inside the truck to support move freely to any site needed without power supplying issue;
5. P10 trailer LED screen provides MINI multimedia control room which supports multiple formats of the input mode,can use GPRS,3G wireless control system;
6.To insure truck LED screen is of high grade anti-shake,before the shipment, each cabinet has to pass a strict anti-vibration test to prevent the damages caused by any improper transportation;



Applications:

Truck LED Display
Truck LED Screen
Trailer Mounted LED Display
Trailer Mounted LED Screen
LED Display Truck Rental
Mobile Truck LED Display
Movable LED Screens
LED Screen Trailer
LED Display Trailer



Specifications :

LED Module Parameter
Pixel pitch (mm)10
Pixel configuration1R1G1B
EncapsulationDIP246
Colors matches6:3:1
Module resolution (pixels)32 x 32
Module pixel1024
Module size (mm)320 x 320
LED CABINET SPECIFICATION
Cabinet size (mm)960 x 960 x 150
Cabinet resolution (pixels)96 x 96
Cabinet pixels (pixels)9216
Cabinet materialSteel
Cabinet weight (kg)50
LED DISPLAY SPECIFICATION
Pixel density(pixel/m2)10000
Brightness(cd/m2)≥8000 (adjustable)
Brightness adjusted100 grade by software or by Auto-optic induced
View angleHorizontal 110°; Vertical 70°
Best viewing distance (m)≥8m
Communication distance(m)<100meter by Internet Cable(without Relay; Multi mode fiber cable < 500m; Single mode
fiber cable < 20km
Display work method1/4 Scan
LED driving methodConstant driving current
Color contrast ratio1800:1
Gray Grade16bit
Display Color439, 804, 651, 110
Refresh Frequency (Hz)≥1000
Picture display methodIntellective control technology , test-itself technology , correct technology, Synchronization
Control
Input signalDVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting )
System operatingWINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc.
Front/Rear IP LevelIP65
Working temperature(ºC)-20~+60
Stored temperature (ºC)-30~+80
Operation humidity(RH)0-95%
Display Lifetime(hours)10 years or more( natural environment) 100000 hours( ideal environment)
MaintenanceRear side
Working VoltageAC110 / AC220V±10% 47~63HZ
Power consumptionMax: 900W/㎡ ; Ave:400W/㎡
Out of controlled dot≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave
length are both >10% depart to the normal one)





Competitive advantages:

1, Far communication distance: P10 truck LED display is utilizing asynchronous control system, also 3G and GPRS synchronous control system is supported; So trailer LED screen is available to park in a far distance without internet cable limit;
2, Quick revenue, as truck LED display is of frequent and convenient use for events, so it can be used more times in a limited time and earn more revenue;
3, P10 trailer LED screen is of high brightness to deliver a clear image and video even under direct sunshine;
4, High resolution: P10 truck LED display is mostly used as high resolution outdoor LED screens;
5, Movable: truck LED screen is convenient to move from one site to next;
6, Self-power supplying: Each mobile truck LED screen is equipped with noiseless generator and this enables truck mobile LED screen park any area without power supply limit;
Trailer LED Screen Rental High Resolution P10 Mounted LED Display 0Trailer LED Screen Rental High Resolution P10 Mounted LED Display 1Trailer LED Screen Rental High Resolution P10 Mounted LED Display 2Trailer LED Screen Rental High Resolution P10 Mounted LED Display 3
