1RGB P6.67 Full Color Outdoor LED Billboard for Advertising IP65 waterproof
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Highlight | led billboard advertising,outdoor led digital billboards |
||
|---|---|---|---|
Product Description
1RGB P6.67 Full Color Outdoor LED Billboard for Advertising IP65 waterproof
Quick Detail:
1, High brightness up to 8000cd/sqm;
2, High resolution:22477 pixel pitches per square meters;
3, Large viewing angle at 140 degree horizontal and vertical;
4, Clear and vivid advertising image and video;
5, High contrast ratio at 4000:1;
6, IP65 waterproof for outdoor use;
Description:
1. High quality image and video presentation for large size LED billboards advertising use;
2. P6.67 outdoor LED billboards is of high resolution for fixed installation outdoor LED screens;
3. High brightness to deliver a clear image and video even under direct sunshine;
4. Brightness automatic adjustment for day and night use;
5. Control software support Linsn,Nova,DBstar,ZQEC etc.
6. Communication distance support less than 100 meters by Lan, under 500 meters by multi mode fiber optic and lower than 20km by single mode fiber optic.
Applications:
On roof of building LED Billboard
Mounted on building LED Billboard
Put on steel pole LED Billboard
Cross bridge information LED Billboard
Shopping Mall LED Billboard
Commercial Advertising LED Billboard
Church LED Billboard
Road Show LED Billboards
High Speed Way LED Advertising Billboard
Specifications :
| LED MODULE PARAMETER | |
| Pixel pitch (mm) | 6.67 |
| Pixel configuration | 1R1G1B |
| Encapsulation | DIP246 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 48 x 48 |
| Module pixel | 2304 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 144 x 144 |
| Cabinet pixels (pixels) | 20736 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 50kg |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 22477 |
| Brightness(cd/m2) | ≥7500 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 140°; Vertical 140° |
| Best viewing distance (m) | ≥6m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/6 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥2800 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1. P6.67 1RGB outdoor LED billboard is of high resolution and better waterproof for outdoor advertising LED screen use;
2. Strong supply ability: 5000㎡ per month LED display production and regular products in stock for quick delivery;
3. Stable quality: Professionally supplied LED screen to over 80 countries and installed thousands projects in 10 years;
4. Innovation: Carefully listen to customer need and create improved LED display products to support local LED sign market development;
5. Trusted service: Local cooperation distributors in Italy,Poland,Malaysia and Thailand; 24/7 LED experts online support; LED engineer on-site support;
6. Strong supply ability: 5000㎡ per month LED display production and regular products in stock for quick delivery;
