3 in 1 DIP P8 Street Digital Outdoor LED Billboard / Stage Background Led Display
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Highlight | led billboard advertising,outdoor digital signage |
||
|---|---|---|---|
Product Description
3 in 1 DIP P8 Street Digital Outdoor LED Billboard / Stage Background Led Display
Quick Detail:
1. Utilizing DIP 3 in 1 LED;
2, LED Chips: Epistar
3. Module: 320mm x 320mm;
4. Cabinet: 960mm x 960mm x 150mm;
5. IP65, waterproof;
6. Better waterproof, long life time.
Description:
1. P8 DIP 3 in 1 outdoor LED billboards is mostly used as high resolution fixed installation outdoor LED screens;
2. High contrast ratio at 4000:1 to display true and natural color of image and video;
3. High brightness to deliver a clear image and video even under direct sunshine;
4. Brightness automatic adjustment for day and night use;
5. Communication distance support less than 100 meters by Lan, under 500 meters by multi mode fiber optic and lower than 20km by single mode fiber optic.
6. High quality image and video presentation for large size LED billboards advertising use;
Applications:
On roof of building LED Billboard
Mounted on building LED Billboard
Put on steel pole LED Billboard
Cross bridge information LED Billboard
Shopping Mall LED Billboard
Commercial Advertising LED Billboard
Church LED Billboard
Road Show LED Billboards
High Speed Way LED Advertising Billboard
Specifications :
| LED Module Parameter | |
| Pixel pitch (mm) | 8 |
| Pixel configuration | 1R1G1B |
| Encapsulation | 3 in 1 |
| Colors matches | 6:3:1 |
| Module resolution (pixels) | 40 x 40 |
| Module pixel | 1600 |
| Module size (mm) | 320 x 320 |
| LED CABINET SPECIFICATION | |
| Cabinet size (mm) | 960 x 960 x 150 |
| Cabinet resolution (pixels) | 120 x 120 |
| Cabinet pixels (pixels) | 14400 |
| Cabinet material | Steel |
| Cabinet weight (kg) | 50 |
| LED DISPLAY SPECIFICATION | |
| Pixel density(pixel/m2) | 15625 |
| Brightness(cd/m2) | ≥8000 (adjustable) |
| Brightness adjusted | 100 grade by software or by Auto-optic induced |
| View angle | Horizontal 110°; Vertical 70° |
| Best viewing distance (m) | ≥7m |
| Communication distance(m) | <100meter by Internet Cable(without Relay; Multi mode fiber cable ＜ 500m; Single mode fiber cable ＜ 20km |
| Display work method | 1/4 Scan |
| LED driving method | Constant driving current |
| Color contrast ratio | 1800:1 |
| Gray Grade | 16bit |
| Display Color | 439, 804, 651, 110 |
| Refresh Frequency (Hz) | ≥1000 |
| Picture display method | Intellective control technology , test-itself technology , correct technology, Synchronization Control |
| Input signal | DVI (S-VIDEO, CVBS, ,DP,HDMI,VGA, PAL/NTSC, etc.through Video processor converting ) |
| System operating | WINDOWS 98, WINDOWS 2000, WINDOWS XP,WINDOWS 7 etc. |
| Front/Rear IP Level | IP65 |
| Working temperature(ºC) | -20～+60 |
| Stored temperature (ºC) | -30～+80 |
| Operation humidity(RH) | 0-95% |
| Display Lifetime(hours) | 10 years or more( natural environment) 100000 hours( ideal environment) |
| Maintenance | Rear side |
| Working Voltage | AC110 / AC220V±10% 47～63HZ |
| Power consumption | Max: 900W/㎡ ; Ave:400W/㎡ |
| Out of controlled dot | ≤3/10,000 (Out of controlled dots means the pixels of which the brightness and the wave length are both >10% depart to the normal one) |
Competitive advantages:
1, P8 DIP 3 in 1 outdoor LED screen is of high resolution for eye catching active advertising effect deliver to more audience and gain more revenues;
2. P8 outdoor LED screen is widely used as truck LED display and LED screen trailer;
3. Standard LED cabinet of IP65,waterproof and dustproof;
4. High brightness up to 8000cd/㎡,and special requirement LED screen projects can reach 10,000nits;
5, The LED billboards present clear vivid image and video even under direct sunshine;
6, DIP 3 in 1 P8 LED billboard is of better heat disipation and longer life time.
